Deskripsi Produk

Flame Retardant Epoxy Resin Potting Compound for 10-35kV Electrical Insulation

Production Formulation

Component	Material	Quantity	Notes
Epoxy resin	LE-8516	100 pbw	Modified saturated epoxy resin system
Hardener	LH-8516	100 pbw	Modified weather-resistant acid anhydride hardener
Filler	Silica Flour	300-350 pbw
Color paste	LC series	3 pbw

Material Properties

Property	Unit	Value
Appearance	Visual	Transparent, light yellow, viscous liquid
Epoxy value	Eq/kg	4.5-5.0
Viscosity at 25°C	mPa.s	500-1000
Density at 25°C	g/cm3	1.16-1.20
Vapour Pressure at 25°C	Pa	<0.01
Flash point	°C	About 135

Processing Parameters

Parameter	Automatic Pressure Gelation	Vacuum Casting
Epoxy/hardener mixture temperature	40°C /1-2 hours	50-60°C /1-1.5hours
Feeding process	Pressure (0.5-5bar)	Vacuum (casting pot)
Mold temperature	130-150°C	105°C / 4-6 hours
Gelation time	10-30mins	80°C/4 hrs+100°C/2hrs+120°C/2hrs
Post cure	130-140°C*6-10 hrs	130-140°C*6-10 hrs

Cured Material Properties

Property	Value	Property	Value
Glass transition temperature Tg (DSC)	60-80°C	Thermal conductivity	0.8-0.9W/mk
Tensile strength	60-80N/mm²	Thermal decomposition	>320°C
Flexural strength	100-130N/mm²	Water absorption (23°C*10days)	0.10-0.20% by wt.
Compressive strength	140-190N/mm²	Water absorption (100°C*60 mins)	0.08-0.15% by wt.
Impact strength	8-16kJ/m²	Surface resistivity	10¹⁴Ω
Curing shrinkage	0.8-1.0%	Volume resistivity	10¹⁵Ω.cm
Flammability (4mm)	HB Class	Dielectric strength	20-30kV/mm
		Loss factor	0.02

Storage Information

Store components in tightly sealed, dry original containers at 6-35°C. Shelf life corresponds to expiration date on label (normally 12 months). Partial emptied containers should be closed tightly immediately after use.
